Description
A professionally organized SketchUp library featuring essential hardware, connection components, gusset plates, brackets, and support elements commonly used in solar mounting structures.
This library is designed to help engineers, designers, and solar professionals save time when creating 3D solar structure models and project visualizations.
Included Components:
SECTION 01 — Fasteners
• HexBolt_M10x50
• HexBolt_M10x80
• HexBolt_M12x50
• HexBolt_M12x80
• HexBolt_M16x100
• Nut_M10
• Nut_M12
• Nut_M16
• Washer_M10
• Washer_M12
• Washer_M16
SECTION 02 — Gusset Plates
• Triangular_GussetPlate_150
• Triangular_GussetPlate_250
SECTION 03 — Connection Brackets
• LBracket_90Deg
• L_Bracket_Slotted
SECTION 04 — Strut Connection Assemblies
• Gusset_Base_Plate_41_Channel
SECTION 05 — Support Components
• Strut41_SupportPost_300
• Strut28_SupportPost_300
Key Features:
✔ Clean and lightweight SketchUp components
✔ Organized naming convention
✔ Ready for solar structure modeling
✔ Easy to modify and reuse
✔ Suitable for rooftop and ground-mounted solar projects
✔ Time-saving library for engineers and designers
File Format:
• SketchUp (.skp)
Developed by NoorSolis Engineering.
